Characteristics Of 2000W High-power Pulsed Fiber Laser
Technical characteristics
- Uniform Control Interface
- Adjustable Frequency Range
- High Single Pulse Energy
- Excellent Light Beam Quality
Optical Properties
- Output power: (W): [email protected]
- Central wavelength: (nm): 1064±5
- Repetition frequency: (kHz): 20-50
- Output power stability: <5%
Output characteristics
- Polarization state: random
- Pulse Width Range(ns):120-160
- Max.Single Pulse Energy(mJ):[email protected]
- Output Fiber Inner Diameter(μm):400/600
- Delivery Cable length (m): 20
Electronic control characteristics
- Input power (V AC ): Three please 380 50/60Hz
- power adjustment range (%): 10-100
Other characteristics
- Dimensions (mm ): 1018*836*850(handle included)Cooling method: water cooling
- Working temperature (℃ ): 10-40
Application of 2000W High-power Pulsed Fiber Laser RFL-P2000
- Rust Removal
- Oil Cleaning
- Mold Surface Treatment
- Paint Stripping
- Welding Surface Pre-treatment
- Portrait Stone Surface Treatment
