450W QCW Fiber Laser

Characteristics Of 450W QCW Fiber Laser

Technical characteristics

• Two Work Modes: Continuous and Pulse
• Peak Output 4500W
• Extremely Stable Output Performance
• Excellent Light Beam Quality
• QBH Output Connector and Optional Output Length
• Air-Cooled Heat Dissipation

Output characteristics

• Average power(CW) (W): 450
• Average power(Pulse) (W): 450
• Max.Output Power(W): 4500
• Max. Pulse Energy(J): 15
• Central wavelength: (nm): 1080±5
• Repetition Frequency(Hz): 50-5000
• Pulse Width(ms): 0.1-75
• Output power instability: ±1.5%
• Red laser: Yes

Electronic control characteristics

• Output connector: QBH
• output fiber core diameter (μm): 50
• BPP(mm.nrad) : <2

Electronic control characteristics

• Input power (V DC ): 48
• Control mode: RS232/AD/ Ethernet
• power adjustment range (%): 10-100

Other characteristics

• Dimensions (mm ): 450*237*739(handle included)
• Weight (kg): <50
• Cooling method: Air-Cooled
• Working temperature (℃ ): 0-40

Application of 450W QCW Fiber Laser RFL-QCW450/4500

• Alternative of Light-Pumped YAG Lasers
• Spot/Seam Welding
• Ceramics Cutting
• Precision Welding /Cutting
• Electronic Parts Processing
• Power Battery Welding
• Soldering
• PCB Welding
